AppendixC—InstallinganMVP428UpgradeCard

146 MultiVOIP®Voice/FaxoverIPGateways



4. Slidethemaincircuitboardoutofthechassisfarenoughtounplugthepowerconnector.



5. Unplugthepowerconnector fromthemaincircuitboard.

6. Slidethemaincircuitboardcompletelyoutofthechassisandplaceonanon‐conductive,static‐safe

tabletopsurface.

7. Removemountinghardware(2screws,2nuts,and4standoffs)fromitspackage.

8. Onthephone‐jacksideofthecircuitcar d, threescrewsattachthecircuitcardtothebackpanel.Twoof

thesescrewsareadjacenttothefourphone‐jackpairs.Removethesetwoscrews.



9. Replacethesetwoscrewswithstandoffs. 



back panel screws (3)

power connector

Screw locations (2)

at phone-jack edge

of board.
