142 MultiVOIP®Voice/FaxoverIPGateways

Appendix A – Cable Pin-Outs

CommandCable

RJ‐45Connector End‐to‐EndPinInfo



RJ‐45connectorplugsintoCommandPort ofMultiVOIP.

DB‐9connectorplugsintoserialportofcommandPC(whichrunsMultiVOIPconfiguration software).

EthernetConnector

ThissectiondescribesthefunctionsoftheindividualconductorsoftheMultiVOIP’sEthernetportonapin‐by‐

pinbasis.

RJ‐45EthernetConnector Pin CircuitSignalName



1 TD+DataTransmitPos itive

2 TD‐DataTransmitNegative

3 RD+DataReceivePositive

6 RD‐DataReceiveNegative



1 2 3 4 5 6 7 8
