TalkAnytime User Guide Technical Configuration

13. Set Log Reporting Method. The Logs screen lets you choose how the Administrator (or webmaster)

will receive log reports about the

TalkAnytime unit’s performance and the phone call traffic that is passing

through it. Log reports can be received in one of two ways:

A. in the

TalkAnytime program (GUI), or

B. via email (SMTP).

Accessing “Logs/Traces” Screen

Pulldown Icon

Shortcut Sidebar

Ctrl + Alt + L

If you enable console messages, you can customize the types of messages to be included/excluded in log

reports by clicking on the “Filters” button and using the Console Messages Filter Settings screen (see

subsequent page). If you use the logging function, select the logging option that applies to your VoIP

system design. If you intend to use a SysLog Server program for logging, click in that Enable check box.

The common SysLog logical port number is 514. If you intend to use the TalkAnytime web browser GUI

for configuration and control of TalkAnytime units, be aware that the web browser GUI does not support

logs directly. However, when the web browser GUI is used, log files can still be sent to the voip

administrator via email (which requires activating the SMTP logging option in this screen).
