Quick Hookup FaxFinder Cabling Guide

8 MultiTech Systems, Inc.

Quick Hookup for FF-120/220

FaxFinder FF-120/220 Hookup

Power Cable

Receptacle

Cabling to your IP network.

RJ-45 connector.

Cabling to telco POTS lines

or PBX station ports.

LINE 1

LINE 2 LAN 1

CONSOLE

RESET

Cabling to computer running

terminal software.

For debugging purposes only.

Connector at FaxFinder: RJ-45.

Connector at computer: DB-9.

Reset

Switch

Line 2 appears

on FF220 only.
