FaxFinder Configuration Guide: 3Com NBX PBX Systems

15. Set the Dial Plan 4 digit DID and Auto Attendent table so digits that start with 559 route to route 9.

Refer to entry 8 below.

Table Create 2 Incoming 4 Digit DID and Auto At

/ Id Entry Digits Min Max Class Prio Route

/ -- ----- ------------ --- --- ------------- ---- -----

TableEntry Create 2 1 0 1 1 Internal 0 4

TableEntry Create 2 2 1 4 4 Internal 0 0

TableEntry Create 2 3 2 4 4 Internal 0 0

TableEntry Create 2 4 3 4 4 Internal 0 0

TableEntry Create 2 5 4 4 4 Internal 0 0

TableEntry Create 2 6 500 3 3 Internal 0 3

TableEntry Create 2 7 55 4 4 Internal 0 3

TableEntry Create 2 8 559 4 4 Internal 0 9

16. Set the route description, refer to route 9 below.

/ Route Description

/ ----- -----------

DestinationRoute Create 1 LocalCO

DestinationRoute Create 2 LocalCONoStrip

DestinationRoute Create 3 Voice Application

DestinationRoute Create 4 Attendant

DestinationRoute Create 5 H323 ConneXtions Ports

DestinationRoute Create 8 8 Pool

DestinationRoute Create 9 9 FF110 FaxFinder

17. Set the route entry destination extention, this will be the extension list created in step 9. Refer to

route 9 below.

/ Route Entry DestinationExtension

/ ----- ----- --------------------

DestinationRouteEntry Create 1 1 *0001

DestinationRouteEntry Create 1 2 *0002

DestinationRouteEntry Create 2 1 *0001

DestinationRouteEntry Create 2 2 *0002

DestinationRouteEntry Create 3 1 *0003

DestinationRouteEntry Create 4 1 *0004

DestinationRouteEntry Create 5 1 *0005

DestinationRouteEntry Create 8 1 *0008

DestinationRouteEntry Create 9 1 *0009
