Note:Youareresponsibleforevaluating,selecting,andimplementingthelockingdeviceandsecurity
feature.Lenovomakesnocomments,judgments,orwarrantiesaboutthefunction,quality,orperformance
ofthelockingdeviceandsecurityfeature.
Left-sideview
Figure3.Left-sideview
1Fanlouvers(left)5USB3.0connector
2MiniDisplayPort
®
connectororThunderbolt™
connector(dependingonthemodel)
6ExpressCardslot(onsomemodels)
3VGAconnector
7Mediacardslot
4Always-OnUSB2.0connector
8Audioconnector
1Fanlouvers(left)
Thefanlouversandtheinternalfanenableairtocirculateinthecomputertoensurepropercooling,
especiallythecoolingofthemicroprocessor.
Note:Toensureproperairow,donotplaceanyobstacleinfrontofthefanlouvers.
2MiniDisplayPortconnector()orThunderboltconnector()
Dependingonthemodel,yourcomputerhasaMiniDisplayPortconnectororThunderboltconnector.
UsetheMiniDisplayPortconnectortoconnectyourcomputertoadevicethatiscompatiblewiththe
MiniDisplayPortinterface,suchasahigh-denitiontelevision.Formoreinformation,see“UsingtheMini
DisplayPortconnector”onpage35
.
UsetheThunderboltconnectortoconnectyourcomputertoadevicethatiscompatiblewiththeMini
DisplayPortinterfaceorThunderboltinterface,suchasahigh-denitiontelevision.Formoreinformation,see
“UsingtheThunderboltconnector”onpage35
.
