Chapter 2 – Activation and Installation

Chapter 2 – Activation and

Installation

Account Activation for Wireless Products

Please refer to the wireless account activation notice included with your unit and located on the MultiConnect CD.

Choose the one for your wireless network provider and follow the directions to activate your account.

Insert the SIM Card into Holder, if Required

The MultiConnect requires the power supply connection to begin operation. It also requires a SIM card (Subscriber

Identity Module) in the MT100A2W-G unit to operate on a GPRS/GSM network. To install the SIM, do the following:

1. Using a small Phillips screwdriver, remove the two SIM door screws and remove the SIM door.

Note: When changing a SIM, ensure that power is removed from the unit.

2. Insert the SIM card into the card holder. The above graphic illustrates the correct SIM card orientation.

3. Verify that the SIM card fits into the holder properly and then replace the cover.

Multi-Tech Systems, Inc. MultiConnect AW User Guide 10


