Chapter 3 – Configuration of your MultiConnect

Chapter 3 - Configuration of your

MultiConnect

The configuration of the MultiConnect varies slightly depending on which unit you are configuring, MT100A2W-G

which has the internal GPRS/GSM wireless modem. The MT100A2W requires a Multi-Tech CDMA, RS232 based

external modem for its cellular connection. The Cellular Port configuration for the MT100A2W-G has more

configuration options than the MT100A2W unit. The differences are detailed in the Cellular Port Configuration.

The following configuration procedures are based on the Windows XP Operating System. Other Windows operating

systems have similar paths to HyperTerminal. See your system’s online Help if you cannot find it.

HyperTerminal

1. Go to Start I All Programs I Accessories I Communications and then click on HyperTerminal.

2. The New Connection screen is displayed. In the Name: window, enter an applicable name for your

MultiConnect connection.

Click OK.

3. The Connect To screen is displayed with the Country/region, Area code, and phone number windows

blanked out.

Multi-Tech Systems, Inc. MultiConnect AW User Guide 13 

Change the Connect using: window to the COM port for the MultiConnect. Click on the down arrow and

select your COM port.
