Step Procedure

8 Connect the appropriate cable to

the ISI card. The ISI552PC has

one DB-9 connector. The DB-9

is a DTE-type serial port suited

for the connection of Data Circuit-

terminating Equipment, or DCEs.

Note: Any cables connected to

the computer should be shielded

to reduce interference.

9 Turn power on to your computer.

If you are using MultiExpress communication

software, note during your communication set-up

that your ISI card is activated by choosing Serial and

then Com port selection. Do not use the MultiTech

ISI selection for this card. The MultiTech ISI selection

is used with ISI models ISI502 and ISI508.

Table 2-1 (cont'd)

ISI Configuration and Installation Procedure
