TalkAnytime Quick Start Instructions Connectivity Test
Connectivity Test
The procedures “Phone/IP Starter Configuration” and “Phonebook Starter Configuration” must be
completed before you can do this procedure.
1. The setup for testing connectivity is shown below.
IP Addr= 65.129.90.2
Ch1 (FXS)
Ch2 (FXS)
Settings:
TalkAnytime
TA-410/810
Voice/Fax Co der field: Automatic
Interface: FXS
Inbound Phonebook
Channel 1
Description field: test-xyz
Ethernet
Po rt
Ethernet
Hub
Command
PC
IP Addr= 65.129.90.3
URL://65.129.90.2/tat.cgi?
Service=test-xyz&
Protocol=TCP&
Codec=G723&
Digits=Yes
No
Setup for Connectivity Test
After the settings shown here have been made in the TalkAnytime Configuration program, click on Save
Setup.
2. From a browser at the command PC, type in the test URL with “Digits=No.”
If a connection is made and the phone connected to Channel 1 of the TalkAnytime unit rings, then
connectivity has been demonstrated.
If a connection cannot be made, skip to Troubleshooting below.
3. From a browser at the command PC, type in the test URL with “Digits=Yes.” At the TalkAnytime client
software, click
Dial.
If a connection is made and the phone connected to Channel 1 of the TalkAnytime unit rings, then
connectivity has been demonstrated.
If a connection cannot be made, skip to Troubleshooting below.
Multi-Tech Systems, Inc. TalkAnyTime User Guide 41
