72
Chapter 6 - RouteFinder Manager
Multi-Tech Systems, Inc. RouteFinder RF802EW User Guide
6 SendJaneDoe Sends the username JaneDoe to the ISP
7 Waitpassword Waits for ISP to send reply password
8 SH1234 Sends password 1234 to ISP
9 Wait====> Waits for ISP to send reply ===>
10 Send1 Selects option 1 (PPP) for this ISP
11 Go Starts PPP mode
12 Hangup Hangs up Modem
Example 3 : Script for Unreliable ISP (2nd ISP backup)
# Login Script Meaning of Each Login Script Command
1 SendATZ Resets modem
2 SendATS0 =1 Sends initial string ATS0 =1 to modem
3 SendATDT8881234 Dials phone number 888-1234
4 WaitCONNECT 12 Waits for ISP to send reply CONNECT. If no reply,
goes to line 12 for ISP #2.
5 Wait username: 12 Waits for ISP to send reply username. If no
response, goes to line 12 for ISP #2.
6 SendJaneDoe Sends the username JaneDoe to ISP
7 Waitpassword Waits for ISP to send reply password
8SH1234 Sends password 1234 to ISP
9 Wait====> Waits for ISP to send reply ===>
10 Send1 Selects option 1 (PPP) for this ISP
11 Go Starts PPP mode (Rest of script ignored)
12 Hangup Hangs up Modem
13 Send AT S0=1 Sends initial string AT SO=1 to modem
14 Send ATDT 8885678 Dials phone number 888-5678 (ISP #2)
15 Wait Connect 23 Waits for ISP to send reply CONNECT. If no
CONNECT, goes to line 23.
16 Wait username: 23 Waits for ISP to send reply username. If no
response, goes to line 23.
17 Send Stephen Sends the username Stephen to ISP
18 Wait password: Waits for the ISP to send password:
19 SH 5678 Sends password 5678 to ISP
20 Wait====> Waits for ISP to send reply ===>
21 Send1 Selects option 1 (PPP) for this ISP
22 Go Starts PPP mode
23 Hangup Hangs up Modem
24 Jump 2 Goes back to line 2 to re-dial ISP #1
Modem String Settings - The most important modem string is the initialization string
because your network device uses it to establish communications with your modem or
ISDN TA. The modem initialization string displayed is the modem or ISDN TA initialization
string entered in the Setup Wizard. For most analog modems, the Standard Modem
selection will work. For additional information, refer to the Modem Settings information
presented in the Software Installation and Configuration Chapter of this User Guide.
Important: There is no standard ISDN TA initialization string. If your ISDN TA is not
included in the modem list, check your ISDN TA Users Guide for information for the
initialization string for an Asynchronous to Synchronous PPP connection. If you are using
only one channel of your ISDN connection, you can enter the Async to Sync PPP
initialization string. If you are bundling your connection channels, use a Multilink-PPP
initialization string. You must also enter the two phone numbers in the Telephone
Number box of the General Settings dialog box. Also verify that your ISDN TA supports
the dial-up string ATDT. Most ISDN TAs support ATDT, but some support ATD or ATDI.
