Cabling

Cabling your ProxyServer

Cabling your ProxyServer involves making the proper Power,

Command Port, and DSU connections, and optionally, the

RS232/V.35 connection. Figure 3 shows the back panel

connectors and the associated cable connections. The table

that follows details the procedures for connecting the cables to

your ProxyServer.

Power Connection

PC Connection

10BASET COMMAND56K DSU POWER

OFF

RS232/V.35

Ethernet Connection

DDS WAN Connection

DCE Connection

Figure 3. Cable Connections
