77
Chapter 6 - RouteFinder Monitor
Status Tab
The
Status
tab provides information about the status of the
WAN Ethernet
and
Async
ports.
1. From the RouteFinder Monitor dialog box, click the
Status
tab.
2. The
Status
tab information displays:
WAN Ethernet:
This indicator light shows that either the IP Routing or the Remote Access function is in use.
Async Port
Modem Power:
The indicator light is lit when the modem power is turned on.
Modem Ready:
The Network Device sends a pre-initialization and initialization command to the modem or ISDN
TA. If this communication is successful, the indicator light will be lit, indicating your modem is
ready to make a connection.
Modem Connected:
If the Network Device has detected that your modem has successfully dialed up a connection to a
remote site, the indicator light will be lit.
PPP Connected:
After a connection is established, if the RouteFinder has detected that the PPP connection is
successful, this indicator light will be lit.
3. To Exit RouteFinder Monitor, close the window.
